XLPE Tubes

Aerofoam® XLPE Tubes are made from closed cell cross linked polyolefin foam with excellent properties in terms of condensation control, long term thermal block and sound absorption. The polyethylene tubes have thicknesses and the diameters, which match most of the usual pipe sizes up to 40” and can be coated with foil or can be plain.

For more information please view our catalogue here.

The Aerofoam® XLPE tubes have a very good dimensional stability, showing a “memory effect” (they tend to come to their original shape after being compressed).

The tubes represent no hazard to the human health, being used no CFC or HCFC in their production and having a very low VOC level. They are considered environmental friendly products (with low Ozone Depletion Potential – ODP – and Global Warming Potential – GWP) and comply with the LEED requirements, helping buildings to get more LEED points.



XLPE_Polyethylene_Tubes_Image_jpeg

PRODUCT

Material:         closed cell cross linked polyolefin (Polyethylene) foam with alupet foil
Density:         30 kg/m³
Thickness:      5 mm, 10 mm, 12 mm, 15 mm, 20 mm, 25 mm, 30 mm, 40 mm, 50 mm
Diameter:       ½’’ – 40’’
Length:          1 m, 1.2 m, 1.5 m
Color:             grey with silver foil



APPLICATIONS

To install Aerofoam® XLPE Polyethylene Tubes in a professional manner, please consult the Installation Handbook.



PROPERTIES

  • Fire rated “CLASS O” as per BS 476 Parts 6 & 7;
  • Very low water vapor permeance (0 perms);
  • Water tight due to the preapplied alupet foil;
  • Very low water absorption rate (0.3% by volume);
  • High thermal efficiency (λ24˚ C = 0.034 W/mK; λ46˚ C = 0.036 W/mK);
  • Wide temperature range (from -50˚ C to +105˚ C);
  • Chemical resistance – resistant of tubing to most chemicals (sodium, silica, fluoride, chloride, etc.);
  • Antibacterial & antifungal;
  • Environmental friendly – ODP = 0 and GWP < 5;
  • Very low VOC emission level ( < 4 µg/m2/hr in 24 hours);
  • Good mechanical resistance;
  • Sound absorption properties;
  • Perfect fit to most of the pipe sizes;
  • Easy and fast to install;
  • Aesthetical look.



TEST REPORTS

xlpe test reports

SIZE CHART

XLPE pipe sections

Pipe section length: < 6″: 1.5 meters; 6″: 1 meter; > 6″: 1.2 meters
Tolerance: Thickness: ±1 – 1.5 mm; Length: ± 1-1.5 cm
Tubes without foil and diameters up to 40″ are also available upon special request.

For more information please download the catalogue here.
